10A 400V 8x32 gG Cylindrical Cartridge Fuse Link 120kA

Photo is representative

10A 400V 8x32 gG Cylindrical Cartridge Fuse Link 120kA

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 420510
GTIN —
Stock status: In stock

priced individually

Net price: £0.61

Gross price

£0.74

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

gG class 8x32 cylindrical fuse link rated 10A at 400V AC. Suits general overcurrent and short-circuit protection on cables, power lines, and equipment in industrial panels and distribution boards.

Ceramic body with silver-plated copper contacts. 120kA breaking capacity gives solid short-circuit coordination in most industrial applications.

  • Rated voltage: 400V +10%
  • Breaking capacity: 120kA
  • Operating class: gG
  • Size: 8x32 (8.5mm x 31.5mm actual)
  • Standards: IEC/EN 60269-1, IEC/EN 60269-2
Specifications

Rated Current

10A

Rated Voltage

400V +10%

Breaking Capacity

120kA

Operating Class

gG

Rated Frequency

42…62Hz

Size

8x32

Dimension A

8.5mm

Dimension B

31.5mm

Dimension C

6.3mm

Power Dissipation

1.0W

Prearcing I²t

120A²s

I²t at 400V

248A²s

Operating Temperature

-40°C … 80°C

Storage Temperature

-40°C … 90°C

Weight

4.1g

Body Material

Ceramic with silver-plated copper contacts

Standards

IEC/EN 60269-1, IEC/EN 60269-2

Compliance

RoHS Compliant
