1mm² 2 Core LSZH Flexible Cable H05Z1Z1-F 300 500V White Sheath

Photo is representative

1mm² 2 Core LSZH Flexible Cable H05Z1Z1-F 300 500V White Sheath

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 21PVC
GTIN —
Stock status: In stock

priced per metre

More arriving soon

Net price: £0.53

Gross price

£0.64

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

LSZH flexible cord cable, 2-core 1mm², rated 300/500V. Suitable for indoor fixed and pendant wiring in public areas — hospitals, shopping centres, airports — where low smoke and zero halogen properties are required.

Class 5 stranded copper conductors, LSZH insulation and sheath throughout.

  • Standard: H05Z1Z1-F
  • Insulation/Sheath: LSZH
  • Core colours: Brown, Blue
  • OD: 7.2mm
  • Temp range: -5°C to +70°C
  • Min bend radius: 5 x OD
Specifications

Conductor Size

1 mm²

Number of Cores

2

Voltage Rating

300/500V

Conductor Type

Class 5 flexible stranded copper

Stranding

32/0.2

Insulation Material

LSZH

Sheath Material

LSZH

Sheath Colour

White

Core Colours

Brown, Blue

Overall Diameter

7.2 mm

Temperature Range

-5°C to +70°C

Min Bending Radius

5 x Overall Diameter

Flame Retardancy

BS EN 60332-1-2

Standard

H05Z1Z1-F / BS EN 50525-3-11
