25A 22x58 aM Cylindrical Fuse Link 690V AC

Photo is representative

25A 22x58 aM Cylindrical Fuse Link 690V AC

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 4420125
GTIN —
Stock status: In stock

priced individually

Net price: £2.48

Gross price

£2.98

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

aM class cylindrical fuse link, 22x58mm. Suited to motor circuits, transformers, and other loads with high inrush currents where short-circuit protection is required.

Good current limiting capability and low I²t values help protect downstream switchgear. Silver plated copper contacts, ceramic body.

  • Rated current: 25A
  • Rated voltage: 690V AC (+5%)
  • Breaking capacity: 80kA @ 690V, 120kA @ 500V/400V
  • Operating class: aM
  • Dimensions: 22.2 × 58mm
Specifications

Operating Class

aM

Rated Current

25A

Rated Voltage

690V AC (+5%), 500V AC (+10%), 400V AC (+10%)

Breaking Capacity

80kA @ 690V; 120kA @ 500V/400V

Rated Frequency

42–62 Hz

Power Dissipation

1.53W

Prearcing I²t

1300 A²S

I²t @ 690V

8000 A²S

I²t @ 500V

4851 A²S

I²t @ 400V

3728 A²S

Body Material

Ceramic

Contacts Material

Silver plated copper

Operating Temperature

−40°C to 80°C

Storage Temperature

−40°C to 90°C

Dimensions (A × B × C × D × E)

22.2 × 58 × 16 × 8 × 3.7 mm

Weight

50g

Standards

IEC/EN 60269-1, IEC/EN 60269-2

Certifications

RoHS Compliant
