25A 400V gG Cylindrical Fuse Link 8x32 IEC60269 Ceramic

Photo is representative

25A 400V gG Cylindrical Fuse Link 8x32 IEC60269 Ceramic

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 425025
GTIN —
Stock status: In stock

priced individually

Net price: £0.81

Gross price

£0.97

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

Cylindrical gG fuse link in the 8x32 format (8.5x31.5mm). Sized for fuse holders and carriers taking this format. Class gG covers full-range protection — overloads and short circuits — for cables, power lines, and equipment.

Ceramic body with silver-plated copper contacts. Compliant with IEC/EN 60269-1 and 60269-2, RoHS compliant.

  • Rated current: 25A
  • Rated voltage: 400V +10%
  • Breaking capacity: 120kA
  • Operating temperature: -40°C to +80°C
  • Power dissipation: 2.5W
Specifications

Operating Class

gG

Rated Current

25A

Rated Voltage

400V +10%

Breaking Capacity

120kA

Rated Frequency

42…62Hz

Dimension A

8.5mm

Dimension B

31.5mm

Dimension C

6.3mm

Body Material

Ceramic

Contact Material

Silver plated copper

Power Dissipation

2.5W

Prearcing I²t

800 A²s

I²t at 400V

1688 A²s

Operating Temperature

-40°C to +80°C

Storage Temperature

-40°C to +90°C

Weight

4.1g

Standards

IEC/EN 60269-1, IEC/EN 60269-2, RoHS
