3 Core 1mm² H05Z1Z1-F LSZH Flexible Cable 300 500V White Sheath

Photo is representative

3 Core 1mm² H05Z1Z1-F LSZH Flexible Cable 300 500V White Sheath

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 31PVC
GTIN —
Stock status: In stock

priced per metre

More arriving soon

Net price: £0.83

Gross price

£0.99

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

H05Z1Z1-F LSZH flexible cable, 3 core 1mm². Rated 300/500V with Class 5 flexible stranded copper conductors. White LSZH outer sheath with brown, blue, and green/yellow cores.

Suited to indoor fixed wiring in public areas — pendant lighting, general supply leads in hospitals, shopping centres, and airports where low smoke and zero halogen properties are required.

  • 1mm² Class 5 stranded copper, 32⁄0.2mm
  • LSZH insulation and sheath
  • OD: 7.6mm | Min. bend radius: 5 x OD
  • Temp range: -5°C to +70°C
  • Flame retardant to BS EN 60332-1-2
Specifications

Conductor Size

1 mm²

Number of Cores

3

Voltage Rating

300/500V

Conductor Type

Class 5 flexible stranded copper

Conductor Stranding

32/0.2 mm

Insulation Material

LSZH

Sheath Material

LSZH

Sheath Colour

White

Core Colours

Brown, Blue, Green/Yellow

Overall Diameter

7.6 mm

Weight

82 kg/km

Minimum Bending Radius

5 x Overall Diameter

Temperature Range

-5°C to +70°C

Standards

H05Z1Z1-F, BS EN/IEC 60228, BS EN/IEC 60332-1-2, BS EN 50525-3-11
