Photo is representative

30 µF Motor Run Capacitor 450V AC, 6.3mm Spade Terminals

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 416172160
GTIN —
Stock status: In stock

priced individually

Net price: £9.27

Gross price

£11.12

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

30 µF motor run capacitor rated 450V AC, 50–60Hz for continuous operation in the run winding of single-phase induction motors such as pumps, fans and compressors.

  • Capacitance: 30 µF ±5%
  • Voltage: 450V AC nominal (425V / 30 000h class A, 475V / 10 000h class B), 50–60Hz
  • Terminal type: 6.3mm spade (faston), 4 tabs
  • Operating temperature: −25°C to +85°C
  • Case dimensions: Ø45.5 × 92 mm
  • Case shape: Round
  • Dielectric: metallized polypropylene film (self-healing)
  • Compliance: CE, UKCA (also VDE, UL); EN 60252-1
Specifications

Capacitance

30 µF ±5%

Voltage

450V AC (425V cl. A / 475V cl. B)

Frequency

50–60 Hz

Terminal type

6.3mm spade (faston)

Case shape

Round

Case dimensions

Ø45.5 × 92 mm

Operating temperature

−25 to +85 °C

Dielectric

Metallized polypropylene film

Compliance

CE, UKCA, VDE, UL

Standard

EN 60252-1/A1
