5 Core 0.75mm2 H05Z1Z1-F LSZH Flexible Cable 300 500V White Sheath

Photo is representative

5 Core 0.75mm2 H05Z1Z1-F LSZH Flexible Cable 300 500V White Sheath

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 575PVC
GTIN —
Stock status: In stock

priced per metre

More arriving soon

Net price: £1.10

Gross price

£1.32

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

5-core LSZH flex rated at 300/500V. Designed for fixed indoor wiring in public areas — hospitals, airports, shopping centres — where low smoke and zero halogen properties are required.

Class 5 stranded copper conductors (24⁄0.20), LSZH insulation and sheath throughout. Core colours: Brown, Black, Grey, Blue, Green/Yellow.

  • 0.75mm² conductors, 5 cores
  • White LSZH sheath, 8.5mm OD
  • Minimum bend radius: 5 × OD
  • Temp range: –5°C to +70°C
  • BS EN 50525-3-11 | BS EN 60332-1-2 flame retardant
Specifications

Conductor Size

0.75 mm²

Number of Cores

5

Voltage Rating

300/500 V

Conductor Type

Class 5 flexible stranded copper

Stranding

24/0.20

Insulation Material

LSZH

Sheath Material

LSZH

Sheath Colour

White

Core Colours

Brown, Black, Grey, Blue, Green/Yellow

Overall Diameter

8.5 mm

Weight

110 kg/km

Gland Size

20S

Minimum Bending Radius

5 × Overall Diameter

Temperature Range

–5°C to +70°C

Standard

H05Z1Z1-F

Compliance

BS EN 50525-3-11, BS EN/IEC 60228, BS EN/IEC 60332-1-2
