5 Core 1.5mm² LSZH Flexible Cable 300 500V White Sheath H05Z1Z1-F

Photo is representative

5 Core 1.5mm² LSZH Flexible Cable 300 500V White Sheath H05Z1Z1-F

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 515PVC
GTIN —
Stock status: In stock

priced per metre

Net price: £1.94

Gross price

£2.33

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

5-core 1.5mm² LSZH flexible cable for indoor fixed wiring in public buildings — hospitals, shopping centres, airports. Suitable for pendant lighting and general supply leads where low smoke and zero halogen properties are required.

Both insulation and sheath are LSZH. Not for use outdoors or direct burial.

  • 300/500V rated
  • Class 5 stranded copper, 30⁄0.25 stranding
  • Core colours: Brown, Black, Grey, Blue, Green/Yellow
  • 11mm OD, 20mm gland size
  • Flame retardant to BS EN 60332-1-2
Specifications

Conductor Size

1.5 mm²

Number of Cores

5

Voltage Rating

300/500 V

Conductor Type

Class 5 flexible stranded copper

Stranding

30/0.25

Insulation Material

LSZH

Sheath Material

LSZH

Sheath Colour

White

Core Colours

Brown, Black, Grey, Blue, Green/Yellow

Overall Diameter

11 mm

Weight

180 kg/km

Gland Size

20 mm

Minimum Bending Radius

5 x overall diameter

Temperature Range

-5°C to +70°C

Standards

H05Z1Z1-F, BS EN/IEC 60228, BS EN/IEC 60332-1-2, BS EN 50525-3-11
