50A 22x58mm aM Cylindrical Fuse Link 690V AC

Photo is representative

50A 22x58mm aM Cylindrical Fuse Link 690V AC

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 442050
GTIN —
Stock status: In stock

priced individually

Net price: £2.72

Gross price

£3.27

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

22x58mm aM class cylindrical fuse link, 50A. Suited to motor circuits, transformers and other loads with high inrush currents where short-circuit protection is needed.

  • Rated current: 50A
  • Rated voltage: 690V AC
  • Breaking capacity: 80kA @ 690V, 120kA @ 500V/400V
  • Prearcing I²t: 10,000 A²S
  • Standards: IEC/EN 60269-1, IEC/EN 60269-2
Specifications

Operating Class

aM

Rated Current

50A

Size

22x58mm

Rated Voltage

690V AC / 500V AC / 400V AC

Breaking Capacity

80kA @ 690V; 120kA @ 500V/400V

Rated Frequency

42–62Hz

Prearcing I²t

10000 A²S

I²t @ 690V

32000 A²S

I²t @ 500V

23230 A²S

I²t @ 400V

19626 A²S

Power Dissipation

3.48W

Body Material

Ceramic

Contact Material

Silver plated copper

Operating Temperature

-40°C to 80°C

Storage Temperature

-40°C to 90°C

Weight

50g

Dimensions (A × B × C × D × E)

22.2 × 58 × 16 × 8 × 3.7 mm

Standards

IEC/EN 60269-1, IEC/EN 60269-2

RoHS Compliant

Yes
