63A 22x58mm gG Cylindrical Fuse Link 690V AC

Photo is representative

63A 22x58mm gG Cylindrical Fuse Link 690V AC

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 422063
GTIN —
Stock status: In stock

priced individually

Net price: £3.33

Gross price

£3.99

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

gG class cylindrical fuse link, 22x58mm, rated 63A at 690V AC. General protection for cables, power lines and equipment against overloads and short circuits. Ceramic body with silver plated copper contacts.

  • Rated current: 63A
  • Rated voltage: 690V AC
  • Breaking capacity: 80kA @ 690V
  • Size: 22x58mm
  • Standards: IEC/EN 60269-1, IEC/EN 60269-2
Specifications

Operating Class

gG

Rated Current

63A

Rated Voltage

690V AC

Breaking Capacity

80kA @ 690V

Size

22x58mm

Rated Frequency

42–62Hz

Power Dissipation

5.95W

Prearcing I²t

10000 A²S

I²t @ 690V

39000 A²S

I²t @ 500V

26811 A²S

I²t @ 400V

22011 A²S

Operating Temperature

-40°C to 80°C

Storage Temperature

-40°C to 90°C

Body Material

Ceramic

Contact Material

Silver plated copper

Weight

50g

Standards

IEC/EN 60269-1, IEC/EN 60269-2

RoHS Compliant

Yes
