6491B 2.5mm Single Core Earth Cable LSZH Yellow Green 450 750V 500m

Photo is representative

6491B 2.5mm Single Core Earth Cable LSZH Yellow Green 450 750V 500m

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 2.5PVCEARTH5
GTIN —
Stock status: In stock

priced per metre

More arriving soon

Net price: £0.63

Gross price

£0.75

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

6491B single core earth cable in 2.5mm², yellow/green LSZH sheath. Suited for conduit installs, fixed wiring, lighting, switchgear and appliances. LSZH sheath keeps smoke, halogen emissions and toxic fumes to a minimum — important in occupied or sensitive buildings.

  • 2.5mm² Class 2 stranded copper, 7⁄0.67mm
  • 450/750V rated, 0°C to +90°C operating range
  • OD: 3.65mm, min bend radius (fixed): 6 x OD
  • Flame retardant to BS EN 60332-1-2
  • Standards: H07Z-R, BS EN 50525-3-41, BS EN/IEC 60228
Specifications

Conductor Size

2.5 mm²

Number of Cores

1

Core Colour

Yellow/Green

Conductor Type

Class 2 stranded copper

Stranding

7/0.67 mm

Overall Diameter

3.65 mm

Sheath Material

Low Smoke Zero Halogen (LSZH)

Voltage Rating

450/750 V

Temperature Range

0°C to +90°C

Min Bending Radius (Fixed)

6 x overall diameter

Flame Retardancy

BS EN 60332-1-2

Weight

33 kg/km

Standards

H07Z-R, BS EN/IEC 60228, IEC/EN 61034-1/2, BS EN/IEC 60332-1-2, BS EN 50525-3-41
