6491B H07Z-R 150mm Single Core LSZH Earth Cable Yellow Green 450 750V

Photo is representative

6491B H07Z-R 150mm Single Core LSZH Earth Cable Yellow Green 450 750V

Product Information

Stock Code 150PVCEARTH
GTIN —
Stock status: In stock

priced per metre

Net price: £23.82

Gross price

£28.58

This item is not available to order online. Contact us to arrange supply.

Single core 150mm² earth cable to H07Z-R. Yellow/green LSZH sheath — suited for conduit runs, fixed installations, switchgear, and control gear where fire, smoke, and toxic fume emission is a concern.

Class 2 stranded copper conductor, 37⁄2.25mm stranding.

  • Voltage rating: 450/750V
  • Overall diameter: 19.1mm
  • Temp range: 0°C to +90°C
  • Min bending radius (fixed): 6 x OD
  • Flame retardancy: BS EN 60332-1-2
Specifications

Conductor Size

150 mm²

Number of Cores

1

Core Colour

Yellow/Green

Voltage Rating

450/750V

Conductor Type

Class 2 stranded copper

Stranding

37/2.25 mm

Sheath Material

Low Smoke Zero Halogen (LSZH)

Overall Diameter

19.1 mm

Weight

1510 kg/km

Temperature Range

0°C to +90°C

Min Bending Radius (Fixed)

6 x overall diameter

Flame Retardancy

BS EN 60332-1-2

Standards

H07Z-R, BS EN/IEC 60228, IEC/EN 61034-1/2, BS EN/IEC 60332-1-2
