6491B H07Z-R 16mm Single Core Earth LSZH Yellow Green 450 750V

Photo is representative

6491B H07Z-R 16mm Single Core Earth LSZH Yellow Green 450 750V

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 16PVCEARTH1
GTIN —
Stock status: In stock

priced per metre

More arriving soon

Net price: £3.18

Gross price

£3.81

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

Single core 16mm² earth cable to H07Z-R. LSZH sheathed, yellow/green, for use in conduit and fixed protection installations. Suited to lighting circuits, switchgear, and control gear where smoke and toxic fume emission is a concern.

Class 2 stranded copper conductor, 7⁄1.70mm stranding.

  • 450/750V rated
  • LSZH sheath — flame retardant to BS EN 60332-1-2
  • OD 7.1mm, min. fixed bend radius 6 × OD
  • Temp range 0°C to +90°C
  • Conforms to BS EN 50525-3-41, BS EN/IEC 60228
Specifications

Conductor Size

16mm²

Number of Cores

1

Core Colour

Yellow/Green

Voltage Rating

450/750V

Conductor Type

Class 2 stranded copper

Stranding

7/1.70mm

Sheath Material

Low Smoke Zero Halogen (LSZH)

Overall Diameter

7.1mm

Weight

175 kg/km

Temperature Range

0°C to +90°C

Min. Bending Radius (Fixed)

6 × overall diameter

Flame Retardancy

BS EN 60332-1-2

Standard

BS EN 50525-3-41 (H07Z-R)

Conforms To

BS EN/IEC 60228, IEC/EN 61034-1/2, BS EN/IEC 60332-1-2
