6491B H07Z-R 185mm² Single Core LSZH Earth Cable Yellow Green 450 750V

Photo is representative

6491B H07Z-R 185mm² Single Core LSZH Earth Cable Yellow Green 450 750V

Product Information

Stock Code 185PVCEARTH
GTIN —
Stock status: In stock

priced per metre

More arriving soon

Net price: £35.18

Gross price

£42.22

This item is not available to order online. Contact us to arrange supply.

Single core 185mm² earth cable to H07Z-R spec, LSZH sheathed in yellow/green. Suited for conduit and fixed protection installations — lighting, switchgear, control gear and appliances.

LSZH sheath is required where smoke, toxic fumes or halogen emissions are a concern in the event of fire.

  • 185mm² Class 2 stranded copper conductor (37⁄2.52)
  • 450/750V rated
  • OD: 21.3mm | Weight: 1900 kg/km
  • Temp range: 0°C to +90°C
  • Flame retardant to BS EN 60332-1-2
Specifications

Conductor Size

185 mm²

Number of Cores

1

Core Colour

Yellow/Green

Voltage Rating

450/750V

Conductor Type

Class 2 stranded copper

Stranding

37/2.52

Sheath Material

Low Smoke Zero Halogen (LSZH)

Overall Diameter

21.3 mm

Weight

1900 kg/km

Temperature Range

0°C to +90°C

Minimum Bending Radius (Fixed)

6 x overall diameter

Flame Retardancy

BS EN 60332-1-2

Standards

H07Z-R, BS EN 50525-3-41, BS EN/IEC 60228, IEC/EN 61034-1/2, BS EN/IEC 60332-1-2
