6491B H07Z-R 2.5mm Single Core Blue LSZH Cable 450 750V

Photo is representative

6491B H07Z-R 2.5mm Single Core Blue LSZH Cable 450 750V

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 2.5PVCBLUE5
GTIN —
Stock status: In stock

priced per metre

More arriving soon

Net price: £0.62

Gross price

£0.75

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

Single core 2.5mm² blue LSZH cable to H07Z-R. Suited for conduit and fixed protection installations — lighting circuits, switchgear, and control gear.

LSZH sheath makes it the right pick where fire, smoke, and toxic fume emissions are a concern.

  • 2.5mm² Class 2 stranded copper, 7⁄0.67mm
  • 450/750V rated
  • OD: 3.65mm
  • Temp range: 0°C to +90°C
  • Flame retardant to BS EN 60332-1-2
Specifications

Conductor Size

2.5 mm²

Number of Cores

1

Core Colour

Blue

Voltage Rating

450/750 V

Conductor Type

Class 2 stranded copper

Stranding

7/0.67 mm

Overall Diameter

3.65 mm

Weight

33 kg/km

Sheath Material

Low Smoke Zero Halogen (LSZH)

Temperature Range

0°C to +90°C

Minimum Bending Radius (Fixed)

6 × overall diameter

Flame Retardancy

BS EN 60332-1-2

Standards

H07Z-R, BS EN/IEC 60228, IEC/EN 61034-1/2, BS EN/IEC 60332-1-2, BS EN 50525-3-41
