6491B H07Z-R 2.5mm Single Core LSZH Brown 450 750V 500m

Photo is representative

6491B H07Z-R 2.5mm Single Core LSZH Brown 450 750V 500m

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 2.5PVCBROWN5
GTIN —
Stock status: In stock

priced per meter

More arriving soon

Net price: £0.63

Gross price

£0.75

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

Single core 6491B cable to H07Z-R. Brown LSZH sheathed, 2.5mm² Class 2 stranded copper. Rated 450/750V.

Suited to conduit and fixed protection installations — lighting circuits, switchgear, and control gear. LSZH sheath meets BS EN 60332-1-2 flame retardancy, with low smoke and zero halogen output if the cable is involved in a fire.

  • Conductor: 2.5mm² Class 2 stranded, 7⁄0.67
  • Overall diameter: 3.65mm
  • Temp range: 0°C to +90°C
  • Min bending radius (fixed): 6 x OD
Specifications

Voltage Rating

450/750V

Conductor Size

2.5mm²

Number of Cores

1

Conductor Type

Class 2 stranded copper

Stranding

7/0.67

Overall Diameter

3.65mm

Weight

33 kg/km

Sheath Material

Low Smoke Zero Halogen (LSZH)

Temperature Range

0°C to +90°C

Min Bending Radius (Fixed)

6 x overall diameter

Core Colour

Brown

Flame Retardancy

BS EN 60332-1-2

Standards

H07Z-R, BS EN/IEC 60228, IEC/EN 61034-1/2, BS EN/IEC 60332-1-2
