6491B Single Core LSZH 10mm2 Earth Cable Yellow Green 450 750V

Photo is representative

6491B Single Core LSZH 10mm2 Earth Cable Yellow Green 450 750V

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 10PVCEARTH5
GTIN —
Stock status: In stock

priced per metre

More arriving soon

Net price: £1.99

Gross price

£2.38

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

Single core 6491B earth cable in 10mm² yellow/green. LSZH sheathed, rated 450/750V. Suited for conduit runs and fixed wiring — lighting circuits, switchgear, and control gear installations.

LSZH sheath makes it the right call where fire and smoke emissions are a concern.

  • 10mm² Class 2 stranded copper, 7⁄1.35mm stranding
  • OD: 6.15mm — minimum fixed bend radius 6 x OD
  • Temp range: 0°C to +90°C
  • Flame retardancy: BS EN 60332-1-2
  • Standards: H07Z-R, BS EN/IEC 60228, IEC/EN 61034-1⁄2
Specifications

Voltage Rating

450/750V

Conductor Size

10mm²

Cores

1

Core Colour

Yellow/Green

Conductor

Class 2 stranded copper

Stranding

7/1.35mm

Overall Diameter

6.15mm

Sheath

Low Smoke Zero Halogen (LSZH)

Temperature Range

0°C to +90°C

Min Bending Radius (Fixed)

6 x overall diameter

Weight

116 kg/km

Flame Retardancy

BS EN 60332-1-2

Standards

H07Z-R, BS EN/IEC 60228, IEC/EN 61034-1/2, BS EN/IEC 60332-1-2
