6491B Single Core LSZH 4mm² Earth Yellow Green 450 750V H07Z-R 500m

Photo is representative

6491B Single Core LSZH 4mm² Earth Yellow Green 450 750V H07Z-R 500m

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 4PVCEARTH5
GTIN —
Stock status: In stock

priced per metre

More arriving soon

Net price: £0.96

Gross price

£1.16

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

Single core 4mm² LSZH earth cable in yellow/green. H07Z-R rated at 450/750V with a Class 2 stranded copper conductor (7⁄0.85mm). Suited for conduit and fixed installation work — lighting circuits, switchgear, and control gear.

LSZH sheath means it’s the right call where fire, smoke, and toxic fume emissions are a concern.

  • 4mm² Class 2 stranded copper, 7⁄0.85mm
  • 450/750V, H07Z-R standard
  • LSZH sheath, 0°C to +90°C operating range
  • OD: 4.2mm, min bending radius (fixed): 6 x OD
  • Flame retardant to BS EN 60332-1-2
Specifications

Conductor Size

4 mm²

Number of Cores

1

Core Colour

Yellow/Green

Voltage Rating

450/750V

Standard

H07Z-R

Conductor Type

Class 2 stranded copper

Stranding

7/0.85 mm

Sheath Material

Low Smoke Zero Halogen (LSZH)

Overall Diameter

4.2 mm

Temperature Range

0°C to +90°C

Minimum Bending Radius (Fixed)

6 x overall diameter

Flame Retardancy

BS EN 60332-1-2

Conforms To

BS EN/IEC 60228, IEC/EN 61034-1/2, BS EN/IEC 60332-1-2

Weight

49 kg/km
