6A aM Cylindrical Fuse Link 14x51 690V AC IEC60269

Photo is representative

6A aM Cylindrical Fuse Link 14x51 690V AC IEC60269

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 441006
GTIN —
Stock status: In stock

priced individually

Net price: £1.31

Gross price

£1.58

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

14x51mm aM class cylindrical fuse link rated at 6A, 690V AC. Designed for short-circuit protection on motor, transformer, and other high inrush current loads — not for overload protection.

Good current limiting capability with low I²t values. Ceramic body with silver-plated copper contacts.

  • Rated voltage: 690V AC (+5%)
  • Breaking capacity: 80kA @ 690V
  • Prearcing I²t: 120 A²S
  • Frequency: 42–62Hz
  • Operating temp: -40°C to +80°C
Specifications

Rated Current

6A

Rated Voltage

690V AC +5%

Operating Class

aM

Breaking Capacity

80kA @ 690V

Rated Frequency

42–62Hz

Prearcing I²t

120 A²S

I²t @ 690V

425 A²S

Power Dissipation

0.42W

Dimensions (A×B×C×D×E)

14.3 × 51 × 13 × 8 × 3.7 mm

Weight

18g

Body Material

Ceramic

Contact Material

Silver plated copper

Operating Temperature

-40°C to +80°C

Storage Temperature

-40°C to +90°C

Standards

IEC/EN 60269-1, IEC/EN 60269-2

RoHS

Compliant
