8A 14x51mm aM Cylindrical Fuse Link 690V AC IEC EN 60269

Photo is representative

8A 14x51mm aM Cylindrical Fuse Link 690V AC IEC EN 60269

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 441008
GTIN —
Stock status: In stock

priced individually

Net price: £1.73

Gross price

£2.07

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

14x51mm aM cylindrical fuse link rated 8A. Designed for motor, transformer and inductive load circuits where high inrush currents rule out gG fuses.

Provides current limiting short-circuit protection with low I²t values — suited for coordination with downstream switchgear.

  • Rated voltage: 690V AC (+5%), 500V AC (+10%), 400V AC (+10%)
  • Breaking capacity: 80kA @ 690V / 120kA @ 500V and 400V
  • Operating class: aM
  • Standards: IEC/EN 60269-1, IEC/EN 60269-2
  • RoHS compliant
Specifications

Rated Current

8A

Rated Voltage

690V AC +5%, 500V AC +10%, 400V AC +10%

Breaking Capacity

80kA @ 690V; 120kA @ 500V/400V

Operating Class

aM

Size

14x51mm

Rated Frequency

42…62Hz

Operating Temperature

-40°C … 80°C

Storage Temperature

-40°C … 90°C

Power Dissipation

0.70W

Prearcing I²t

220 A²S

I²t @ 690V

750 A²S

I²t @ 500V

535 A²S

I²t @ 400V

448 A²S

Dimensions (A × B × C × D × E)

14.3 × 51 × 13 × 8 × 3.7 mm

Weight

18g

Standards

IEC/EN 60269-1, IEC/EN 60269-2

RoHS Compliant

Yes
