Schneider TeSys D 9A 110V AC 3P Contactor LC1D09F7 front view

Photo is representative

Schneider TeSys D 9A 110V AC 3P Contactor - LC1D09F7

Schneider TeSys D 9A 110V AC 3P contactor (LC1D09F7), suitable for direct-on-line (DOL) motor starting and industrial motor control applications. AC-3 rated at 9A for motors up to 4kW (400/440V AC). Features a 3-pole (3NO) main contact configuration, integrated 1NO + 1NC auxiliary contacts, and a 110V AC 50/60Hz coil. Screw clamp terminals enable secure wiring, while DIN rail or panel mounting ensures easy installation. Complies with IEC 60947-4-1 and other international standards for safe, reliable operation in control panels and automation systems.

Product Information

Stock Code LC1D09F7
MPN LC1D09F7
GTIN 3389110348798
Stock status: 2 available
Price: £38.35
incl. VAT, 20% priced individually

Original price: £42.62

10% off - Save £4.26

Product Features
Current Rating 9A AC-3, 25A AC-1
Control Coil 110V AC 50/60Hz
Contact Configuration 3P (3 NO power contacts) + 1NO+1NC auxiliary contacts
Frame Size D-frame
Terminal Type Screw clamp terminals
Mounting Method 35mm DIN rail or panel mount
Auxiliary Capability Accepts up to 4 auxiliary contact blocks
Mechanical Life 15 million operations
Standards Compliance IEC 60947-4-1, IEC 60947-5-1, UL, CSA, EN 60947-4-1

Brand

Schneider Electric
