Front view of Schneider TeSys K LC1K0910P7 3P mini contactor

Photo is representative

Schneider TeSys K 9A 230V AC 3P Mini Contactor - LC1K0910P7

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code LC1K0910P7
GTIN 3389110364521
Stock status: In stock

priced individually

Net price: £33.33

Gross price

£39.99

Schneider TeSys K 9A 230V AC 3P mini contactor (LC1K0910P7) for compact motor and load switching. Rated AC-3/AC-3e 9 A at up to 440 V and AC-1 20 A at up to 690 V, with one instantaneous 1NO auxiliary contact for signalling. Designed for small motor DOL, lighting and resistive loads — motor ratings up to 4 kW (380–415 V AC, AC-3). Screw clamp terminals, low hold-in power and 35 mm DIN-rail compatible compact package (58 x 45 x 57 mm). Conforms to EN/IEC 60947-4-1 and related international standards.

Specifications

Current Rating

9 A (AC-3/AC-3e at ≤ 440 V); 20 A (AC-1 at ≤ 690 V)

Control Coil

230 V AC 50/60 Hz

Contact Configuration

3 power poles (3 NO) + 1 NO instantaneous auxiliary contact

Frame Size

TeSys K (mini) — ultra-compact

Terminal Type

Screw clamp terminals; solid 1.5…4 mm², flexible 0.75…4 mm² (various single/dual cable options)

Mounting Method

35 mm DIN rail or panel mount by adapter (compact dimensions 58 × 45 × 57 mm)

Motor Rating (AC-3)

2.2 kW at 220–230 V; 4 kW at 380–415 V; 4 kW at 440–690 V

Mechanical Life

10 million mechanical cycles

Electrical Durability

1.3 million cycles at 9 A AC-3 (≤ 440 V)

Inrush / Hold-in Power

Inrush 30 VA; Hold-in 4.5 VA (at 20 °C)

Rated Making/Breaking Capacity

Irms making 110 A; breaking up to 110 A at 220–440 V (IEC 60947) — see datasheet for higher voltages

Short-time Withstand (Icw)

90 A (1 s) down to 20 A (≥15 min) depending on time and temperature (see datasheet)

Associated Fuse Rating

25 A gG (power circuit ≤ 440 V); 10 A gG (signalling circuit)

Operating Time

10–20 ms energisation (NO closing); 10–20 ms de-energisation (NO opening)

Standards & Certifications

EN/IEC 60947-4-1, UL/CSA variants, CB, CCC, EAC, CE, UKCA

Environmental / Mechanical

Operating altitude 2000 m without derating; vibration and shock ratings to IEC 60068-2; UL 94 V1 flame retardant
