aM Cylindrical Fuse Link 10x38mm 2A 500V AC 440002

Photo is representative

aM Cylindrical Fuse Link 10x38mm 2A 500V AC 440002

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 440002
GTIN —
Stock status: In stock

priced individually

More arriving soon

Net price: £1.02

Gross price

£1.23

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

aM class cylindrical fuse link, 10x38mm format, rated 2A. Designed for short-circuit protection of motors, transformers and other inductive loads with high inrush currents. Ceramic body with silver-plated copper contacts. Low I²t values suit it for switchgear protection where current limiting matters.

  • Rated voltage: 500V AC +10% / 400V AC +10%
  • Breaking capacity: 120kA
  • Prearcing I²t: 40A²s
  • Operating temp: -40°C to +80°C
  • Standards: IEC/EN 60269-1, IEC/EN 60269-2
Specifications

Operating Class

aM

Rated Current

2A

Rated Voltage

500V AC +10%, 400V AC +10%

Breaking Capacity

120kA

Rated Frequency

42…62Hz

Size

10x38mm

Body Material

Ceramic

Contacts Material

Silver plated copper

Power Dissipation

0.18W

Prearcing I²t

40A²s

I²t at 500V

99A²s

I²t at 400V

83A²s

Operating Temperature

-40°C … +80°C

Storage Temperature

-40°C … +90°C

Standards

IEC/EN 60269-1, IEC/EN 60269-2

RoHS

Compliant

Weight

8g
