Elkat fork busbar 1P 63A 17.8mm pitch 1m

Photo is representative

Elkat fork busbar 1P 63A 17.8mm pitch 1m

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code IZ101F54
GTIN —
Stock status: In stock

priced individually

More arriving soon

Net price: £12.55

Gross price

£15.06

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

Single-phase insulated fork comb busbar for modular MCB and RCBO distribution boards. 54-way, 1000mm length with 17.8mm module pitch.

PVC insulated in RAL 7035 grey. Conductor is 99.9% ETP copper (CW004A), 10mm² cross-section.

  • Rated current (Ie): 63A
  • Nominal voltage (Ue): 240V AC
  • Rated insulation voltage (Ui): 500V
  • Surge withstand (Uimp): 4kV
  • Standards: IEC 60947-1, IEC 60947-7-1
Specifications

Poles

1P

Rated Current (Ie)

63 A

Nominal Voltage (Ue)

240 V

Rated Insulation Voltage (Ui)

500 V

Surge Withstand (Uimp)

4 kV

Cross-Section

10 mm²

Module Pitch

17.8 mm

Ways / Modules

54

Length

1000 mm

Conductor Material

99.9% ETP Copper CW004A

Insulation Material

PVC

Insulation Colour

RAL 7035 Grey

Standards

IEC 60947-1, IEC 60947-7-1
