Elkat fork busbar 2P 63A 18mm pitch 1m insulated grey IZ102F54

Photo is representative

Elkat fork busbar 2P 63A 18mm pitch 1m insulated grey IZ102F54

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code IZ102F54
GTIN —
Stock status: In stock

priced individually

More arriving soon

Net price: £18.90

Gross price

£22.68

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

Elkat IZ10/2F/54 is a 2-pole insulated comb busbar with fork-type connections. Spans 54 modules at 18mm pitch giving a usable length of 1000mm. Suits modular device installations where fork-type feed rail is required.

PVC-insulated in RAL 7035 grey for touch-safe distribution in boards and assemblies.

  • 10mm² cross-section, 99.9% ETP copper (CW004A)
  • Rated 63A, 240/415V AC
  • Rated insulation voltage 500V, impulse withstand 4kV
  • 54 ways, 18mm pitch, 1000mm overall length
Specifications

Poles

2P

Current Rating (Ie)

63 A

Nominal Voltage (Ue)

240/415 V

Rated Insulation Voltage (Ui)

500 V

Impulse Withstand Voltage (Uimp)

4 kV

Cross-Section

10 mm²

Material

99.9% ETP Copper CW004A

Insulation

PVC

Insulation Colour

RAL 7035 Grey

Pitch

18 mm

Modules

54

Length

1000 mm

Compliance

IEC 60947-1, IEC 60947-7-1
