Gewiss 32A 2P+E Straight Plug 110V IP67 Yellow

Photo is representative

Gewiss 32A 2P+E Straight Plug 110V IP67 Yellow

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code GW60034H
GTIN
Stock status: In stock

priced individually

More arriving soon

Net price: £13.24

Gross price

£15.89

Gewiss GW60034H industrial straight plug to IEC 309 HP standard. 32A, 2P+E configuration, rated 110V. Designed for mobile and temporary supplies in tough environments.

  • IP67 rated (also IP66/IP68/IP69 equivalent)
  • Stainless steel body, nickel-plated pins and sleeves
  • Halogen-free, glow wire tested to 850°C (active)
  • Screw-type cable entry, 2.5–10mm² rigid or 2.5–6mm² flexible
  • IK09 mechanical rating, operating -25 to +55°C
Specifications

Product Code

GW60034H

Rated Current

32 A

Poles

2P+E

Rated Voltage

100–130 V

Frequency

50/60 Hz

IP Rating

IP66/IP67/IP68/IP69

Mechanical Rating

IK09

Operating Temperature

-25 to +55°C

Cable Entry

Screw type

Terminal Capacity

2.5–6 mm² flexible, 2.5–10 mm² rigid

Breaking Capacity

40 A at 1.1 Un

Material

Halogen-free per EN 60754-2

Colour

Yellow

Type

Straight plug
