gG Cylindrical Fuse Link 10x38 6A 500V AC IEC EN 60269

Photo is representative

gG Cylindrical Fuse Link 10x38 6A 500V AC IEC EN 60269

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 420006
GTIN —
Stock status: In stock

priced individually

More arriving soon

Net price: £1.43

Gross price

£1.72

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

10x38mm gG cylindrical fuse link rated 6A at 500V AC. Suits general overcurrent and short-circuit protection on cables, power lines, and equipment.

Ceramic body with silver-plated copper contacts. Also available with visual fusing indicator (ref 420106).

  • Rated voltage: 500V AC / 400V AC
  • Breaking capacity: 120kA
  • Operating temperature: -40°C to +80°C
  • Standards: IEC/EN 60269-1, IEC/EN 60269-2
  • RoHS compliant
Specifications

Rated Current

6A

Rated Voltage

500V AC, 400V AC

Operating Class

gG

Breaking Capacity

120kA

Rated Frequency

42…62Hz

Operating Temperature

-40°C ... 80°C

Storage Temperature

-40°C ... 90°C

Size

10x38mm

Body Material

Ceramic

Contact Material

Silver plated copper

Power Dissipation

0.80W

Weight

8g

Standards

IEC/EN 60269-1, IEC/EN 60269-2

RoHS Compliant

Yes
