Front view Schneider TeSys K LC1K0910B7 3P 9A contactor

Photo is representative

Schneider TeSys K 9A 24V AC 3P Mini Contactor - LC1K0910B7

Schneider TeSys K mini contactor LC1K0910B7 — 3-pole 3 NO power contacts, 9 A (AC-3 / AC-3e at ≤440 V) with 1 NO instantaneous auxiliary contact. 24 V AC 50⁄60 Hz control coil (B7). Screw-clamp terminals, compact 35 mm DIN-rail mounting, IEC 60947-4-1 compliant. Suitable for small motor DOL starting and general control: up to 4 kW at 380–415 V (AC-3), 2.2 kW at 220–230 V (AC-3). Inrush 30 VA, hold-in 4.5 VA, rated impulse withstand 8 kV.

Product Information

Stock Code LC1K0910B7
MPN LC1K0910B7
GTIN 3389110363623
Stock status: 6 available
Price: £38.24
incl. VAT, 20% priced individually

Original price: £42.49

10% off - Save £4.25

Product Features
Current Rating 9 A (AC-3 / AC-3e at ≤ 440 V)
Control Coil 24 V AC, 50/60 Hz (B7)
Contact Configuration 3P power contacts (3 NO) + 1 NO auxiliary (instantaneous)
Frame Size TeSys K (mini)
Terminal Type Screw clamp terminals (solid 1.5–4 mm², flexible 0.75–4 mm²)
Mounting Method 35 mm DIN rail (compact panel/DIN mounting)
Motor Rating (AC-3) 2.2 kW at 220–230 V; 4 kW at 380–415 V; 4 kW at 440/690 V
Utilisation Categories AC-1, AC-3, AC-3e, AC-4
Conventional Free Air Thermal Current (Ith) 20 A (power circuit at 60 °C)
Rated Making/Breaking Capacity Irms making 110 A; breaking up to 110 A (varies by voltage per IEC 60947)
Rated Impulse Withstand 8 kV
Mechanical Life 10 million operations
Electrical Durability 1.3 Mcycles (9 A AC-3 at ≤ 440 V)
Operating Time 10–20 ms energisation / 10–20 ms de-energisation
Inrush / Hold-in Power Inrush 30 VA; Hold-in 4.5 VA (at 20 °C)
Standards Compliance EN/IEC 60947-4-1 (also UL/CSA/JIS equivalents)
Environmental / Mechanical Shock & vibration qualified; operating altitude up to 2000 m without derating; UL94 V1

Brand

Schneider Electric
