Eaton 2 Pole 63 Amp Modular Contactor N/O 248859
The Eaton 2 Pole 63 Amp Modular Contactor N/O 248859 is designed for rated operation voltage of 440V, rated operation current of 63A, with 4 normally open contacts and IP40 degree of protection.
Stock Code:
248859
Online:
1 available
Price 104.81 £
incl. VAT, 20%
priced individually
Product Features
| SKU | 248859 |
|---|---|
| Built-in Depth | 60mm |
| Utility Category | 1 |
| Slider for Hand Switch | No |
| Rated Operating Voltage | 440V |
| Rated Operation Current | 63A |
| Rated Excitation Voltage | 230V |
| Degree of Protection (IP) | IP40 |
| Max. Load Fluorescent Lamp | 4060VA |
| Number of Modular Spacings | 3 |
| Max. Incandescent Lamp Load | 7740W |
| Additional Equipment Possible | Yes |
| Voltage Type (Operating Voltage) | AC |
| Voltage Type (Excitation Voltage) | AC |
| Max. Load Fluorescent Lamp (Duo Circuit) | 8120VA |
| Number of Contacts as Normally Open Contact | 4 |
| Number of Contacts as Normally Closed Contact | 0 |
| Max. Load Fluorescent Lamp (Parallel Compensated) | 2668VA |
