Eaton 2 Row 48 Way Metal Distribution Board Surface Mount IP30 BF-O-2/48-C
Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.
Product Information
priced individually
Net price: £166.72
Gross price
£200.07
Mon‐Fri · Subject to order volume Free delivery available 30 day returns
Empty surface-mount DB from Eaton’s xComfort BF range. Sheet steel enclosure, powder-coated white (RAL 9016), for indoor installation sites. Two rows of 24 modules each — 48 modules total. DIN-rail mounting frame included.
- Voltage: 415 V AC, 50⁄60 Hz
- Protection: IP30, IK07
- Dimensions: 460 mm H × 555 mm W × 150 mm D
- Cable entry: Top and bottom gland plate inserts (top supplied)
- Terminals: N bar — 2 × 25 mm² + 43 × 16 mm²; PE bar — 2 × 25 mm² + 43 × 16 mm²
Fitted with door (single, closed type) with three-point turn-lock, front plates, neutral and PE terminal blocks, and DIN-rail mounting frame. Sealable. EMC version. Operating temperature -5 °C to +40 °C.
Certified to IEC/EN 61439-1, IEC/EN 61439-3, and IEC/EN 62208. RoHS compliant.
