Eaton 3P MCB 80A Type C 20kA AZ Series xEffect
Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.
Product Information
Stock Code
211801
GTIN
4015082118013
Stock status:
In stock
priced individually
More arriving soon
Net price: £132.22
Gross price
£158.66
Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns
Mon‐Fri · Subject to order volume Free delivery available 30 day returns
Three-pole MCB from Eaton’s Moeller xEffect AZ series. Rated to IEC/EN 60947-2 — this is an industrial/commercial device, not a domestic BS EN 60898-1 type. Suits high fault-level distribution boards and switchgear assemblies.
C-curve with 20kA Icu at both 230V and 400V AC. Current limiting class 3, selectivity class 3.
- In: 80A, Type C
- Icu: 20kA at 230/400V AC
- Poles: 3P, 4.5 module width
- Terminal range: 2.5–50mm² (solid or stranded), lift terminals
- Operating temp: -25°C to +55°C
Note: 1°C rise above rated ambient reduces current carrying capacity by 0.5%.
