Eaton RCCB 40A Type A 100mA 10kA 4P 4 Module xPole PFIM

Photo is representative

Eaton RCCB 40A Type A 100mA 10kA 4P 4 Module xPole PFIM

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 235440
GTIN 4015082354404
Stock status: In stock

priced individually

More arriving soon

Net price: £79.72

Gross price

£95.66

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

Four-pole RCCB from Eaton’s xPole PFIM range. Rated at 40A with 100mA IΔn sensitivity and Type A pulse-current protection. Non-delayed operation. Fits standard DIN-rail at 4 modules wide — suits residential and commercial distribution boards.

  • Rated voltage: 230V / 400V AC, 50Hz
  • Breaking capacity: 10kA
  • Terminal capacity: 1.5–35mm² solid, 1.5–16mm² stranded
  • Operating temp: -25°C to +60°C (derate 2.5% per °C above 40°C)
  • IP20 terminals; IP40 achieved with suitable enclosure
Specifications

Rated Current (In)

40 A

Poles

4P

RCD Type

Type A

Rated Residual Current (IΔn)

100 mA

Rated Short-Circuit Strength

10 kA

Tripping Time

Non-delayed

Rated Voltage

230V AC / 400V AC

Frequency

50 Hz

Rated Insulation Voltage (UI)

440 V

Rated Impulse Withstand Voltage (Uimp)

4 kV

Module Width

4 modules (70 mm)

Terminal Capacity (Solid)

1.5–35 mm²

Terminal Capacity (Stranded)

1.5–16 mm²

IP Rating

IP20 (IP40 with suitable enclosure)

Operating Temperature

-25°C to +60°C

Mounting

DIN-rail to IEC/EN 60715

Certification

IEC/EN 61008

Mechanical Life

20000 operations

Electrical Life

4000 operations

Weight

0.302 kg

Documents

datasheet Eaton 235440 Datasheet
