Eaton RCCB 80A Type A 300mA 10kA 4P xPole PFIM

Photo is representative

Eaton RCCB 80A Type A 300mA 10kA 4P xPole PFIM

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 235448
GTIN 4015082354480
Stock status: 5 in stock

priced individually

Net price: £111.61

Gross price

£133.94

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

Eaton xPole PFIM four-pole RCCB rated at 80A with 300mA Type A residual current sensitivity. Suited to residential and commercial distribution boards where four-pole residual current protection is required.

Type A detects both sinusoidal AC and pulsating DC fault currents. Non-delayed tripping. Mounts on DIN rail per IEC/EN 60715, occupying 4 standard modules.

  • Rated current: 80A
  • IΔn: 300mA, Type A
  • Breaking capacity: 10kA
  • Voltage: 230V AC / 400V AC, 50Hz
  • Terminal capacity: 1.5–35mm² solid, 1.5–16mm² stranded
  • Operating temperature: -25°C to +60°C (derate above 40°C)
  • IP20 (IP40 with suitable enclosure)
Specifications

Rated Current (In)

80 A

Rated Residual Current (IΔn)

300 mA

RCD Type

Type A

Poles

4P

Rated Short-Circuit Strength

10 kA

Voltage Rating

230V AC / 400V AC

Frequency

50 Hz

Tripping Time

Non-delayed

Module Width

4 modules (70 mm)

Mounting

DIN rail IEC/EN 60715

Terminal Capacity (Solid)

1.5 mm² – 35 mm²

Terminal Capacity (Stranded)

1.5 mm² – 16 mm²

IP Rating

IP20 (IP40 with suitable enclosure)

Operating Temperature

-25°C to +60°C

Rated Impulse Withstand Voltage (Uimp)

4 kV

Impulse Withstand Current

250 A (partly surge-proof)

Electrical Lifespan

4000 operations

Mechanical Lifespan

20000 operations

Certification

IEC/EN 61008

Dimensions (W x H x D)

70 x 80 x 76 mm

Weight

0.384 kg
