Eaton RCCB 80A Type AC 100mA 10kA 2P 2 Module

Photo is representative

Eaton RCCB 80A Type AC 100mA 10kA 2P 2 Module

Delivery to your region may not be available — you can still add to cart and confirm your address at checkout.

Product Information

Stock Code 235403
GTIN 4015082354039
Stock status: 6 in stock

priced individually

More arriving soon

Net price: £150.73

Gross price

£180.88

Same day dispatch
Mon‐Fri · Subject to order volume Free delivery available 30 day returns

Eaton xPole PFIM two-pole RCCB. Fits residential and commercial DBs on DIN rail. Type AC sensitivity, non-delayed tripping, 2 module wide.

  • Rated current: 80A
  • IΔn: 100mA, Type AC
  • Breaking capacity: 10kA
  • Operating temp: -25°C to +60°C (derate 1.2%/°C above 40°C)
  • Terminal range: 1.5–35mm² solid, 1.5–16mm² stranded
Specifications

Rated Current (In)

80 A

Poles

2P

RCD Type

Type AC

Rated Residual Current (IΔn)

100 mA

Rated Short-Circuit Strength

10 kA

Tripping Time

Non-delayed

Rated Voltage

230 V AC

Frequency

50 Hz

Module Width

2 modules (35 mm)

Mounting

DIN-rail, quick attachment with 2 latch positions

IP Rating

IP20 (IP40 with suitable enclosure)

Terminal Capacity (Solid)

1.5–35 mm²

Terminal Capacity (Stranded)

1.5–16 mm²

Operating Temperature

-25°C to +60°C

Certification

IEC/EN 61008

Documents

datasheet Eaton 235403 Datasheet
