Click CMA146PL 800W 1-Gang Unfurnished Dimmer Plate - Polar White
800W maximum load capacity unfurnished dimmer plate for professional lighting control installations. 1-gang configuration with 2 apertures accepts Click MD series dimmer modules for LED, incandescent and low voltage applications. Screw terminals accept 2.5mm² conductors with 25mm minimum backbox depth requirement. BS 5733 compliant with UKCA marking and antimicrobial treatment achieving 99.9% bacteria kill rate. 25-year warranty provides long-term installation confidence for commercial and domestic projects.
Online:
Product Features
| Load Capacity | 800W Maximum |
|---|---|
| Gang Configuration | 1-Gang with 2 Apertures |
| Module Compatibility | MD9014 LED, MD9001 Push Switch, MD9010 1-10V Dimmer |
| Terminal Type | Brass Screw Terminals |
| Backbox Depth | 25mm Minimum Required |
| Plate Dimensions | 86(W) x 86(H) x 9.5(D)mm |
| Fixing Centres | 60.3mm Horizontal |
| Compliance Standard | BS 5733 with UKCA Marking |
| Ingress Protection | IP20 Rating |
| Operating Temperature | -5°C to +40°C |
| Antimicrobial Treatment | 99.9% Bacteria Kill Rate Certified |
| Warranty Period | 25 Years |
Module Applications
LED Dimming Control
MD9014 dual mode module provides smooth LED dimming from 10-100% with leading/trailing edge compatibility for modern LED fittings.
Non-Dimmable Switching
MD9001 6A push switch module converts plate to simple on/off control for non-dimmable LED or fluorescent lighting circuits.
1-10V Analogue Control
MD9010 module enables professional 1-10V dimming control for commercial LED drivers and fluorescent ballasts requiring analogue signals.
Installation Requirements
Terminal Connections
Brass screw terminals accept 2.5mm² conductors. Torque to 0.6-0.8Nm per BS 5733 requirements for secure long-term connections.
Module Installation
Unfurnished design requires separate dimmer module purchase. Modules clip into apertures after plate installation and circuit connection completion.
Frequently Asked Questions
-
What dimmer modules are compatible with this plate?
Compatible with Click MD9014 100W LED dimmer, MD9001 6A push switch module, and MD9010 1-10V analogue dimmer modules for complete lighting control.
-
What minimum backbox depth is required for installation?
Requires minimum 25mm backbox depth with 60.3mm horizontal fixing centres. Standard 35mm backboxes provide optimal installation clearance for module connections.
-
Can this handle LED lighting circuits up to 800W?
800W maximum load capacity when fitted with appropriate MD9014 LED dimmer module. Module specifications determine actual LED compatibility and dimming performance.
-
Is this suitable for bathroom lighting installations?
IP20 rating limits use to dry locations only. Not suitable for bathroom zones requiring IP44 protection or higher moisture resistance.
