Click GridPro 20A Double Pole Switch Module, 2-Way, Freezer, Polar White

Specifically for fans, this GridPro switch module by Click features a polar white finish. With a 2-way switch and suitable for inductive loads, it ensures reliable operation. Backed by a 10-year warranty.

Stock Code GM2018PWFZ
In stock

This product is not available right now. Contact us for more info.

Product Features

  • SKU

    GM2018PWFZ

  • Brand

    Click

  • Model

    GM2018PW-FZ

  • Range

    GridPro

  • Finish

    Polar White

  • Switch

    Urea

  • Contacts

    Silver on-lay Copper / Brass

  • Warranty

    10years

  • Dimensions

    24.5mm x 50mm x 22.5mm

  • 2 Way Switch

    Yes

  • Body & Insert

    Nylon

  • Insert Colour

    Polar White

  • Switch Finish

    Polar White

  • Terminal Size

    Ø5mm

  • Neon Indicator

    No

  • Product Marking

    Fan

  • Termination Type

    Screw

  • Load Rating Comments

    Suitable for Inductive Loads

  • Inductive Load Rating

    20A

  • Minimum Back Box Depth

    25mm (35mm Flat Plate)

  • Operational Temperature

    -5℃ to +40℃

  • Anti Microbial Certified

    No

  • Rated Voltage, Frequency

    250V, 50Hz

  • Terminal Capacity - Solid

    3 x 2.5mm² or 2 x 4mm²

  • Terminals, Terminal Screws

    Brass, Steel & Yellow Passivated
