Click Ingot Black 50A Double Pole Switch with Neon 1 Gang BS EN 60669
Professional 50A double pole plate switch with neon indicator for high-current applications. Features robust screw terminals accepting 16mm² conductors with 2.5Nm torque specification. Satin chrome finish with black insert provides premium aesthetics. Twin earth terminals and 35mm minimum back box depth ensure secure installation. Red neon indicator clearly shows switching status for safe operation. Complies with BS EN 60669-1 standards with IP20 protection rating. Suitable for commercial kitchens, workshops, and heavy-duty equipment circuits. 20-year manufacturer warranty provides long-term reliability assurance. Precision-engineered contacts with silver overlay ensure consistent switching performance under high loads.
Online:
Product Features
| Current Rating | 50A at 250V AC |
|---|---|
| Gang Configuration | 1 Gang Double Pole |
| Switching Type | Double Pole with Neon Indicator |
| Terminal Type | Screw Terminals Ø6mm |
| Terminal Capacity | 1 x 16mm² Solid Conductor |
| Terminal Torque | 2.5Nm Specification |
| Earth Configuration | Twin Earth Terminals |
| Minimum Back Box | 35mm Depth Required |
| Standards Compliance | BS EN 60669-1 Certified |
| IP Rating | IP20 Indoor Protection |
| Neon Indicator | Red Colour Status Display |
| Finish | Satin Chrome with Black Insert |
| Mounting Centres | 60.3mm Horizontal Fixing |
| Warranty Period | 20 Years Manufacturer Coverage |
Heavy Duty Applications
Commercial Equipment
Ideal for commercial ovens, industrial washers, workshop machinery requiring 50A switching capacity with double pole isolation.
Kitchen Installations
Perfect for commercial kitchen ranges, fryers, and high-power equipment where complete circuit isolation is essential.
Installation Guidelines
Terminal Configuration
Screw terminals accept 16mm² conductors with precision torque setting of 2.5Nm for secure high-current connections.
Mounting Requirements
Requires 35mm minimum depth back box with 60.3mm horizontal fixing centres for proper installation clearance.
Standards & Safety
Compliance Certification
BS EN 60669-1 certified with IP20 protection rating, ensuring professional installation standards and regulatory compliance.
Operational Limits
Rated for -5°C to +40°C operation with 20-year warranty coverage providing long-term reliability assurance.
Frequently Asked Questions
-
What cable size does this 50A switch accept?
Accepts 1 x 16mm² solid conductor per terminal with Ø6mm screw terminals rated to 2.5Nm torque specification.
-
What back box depth is required for installation?
Requires minimum 35mm deep back box due to robust terminal configuration and internal switching mechanism dimensions.
-
Is this switch suitable for commercial kitchen equipment?
Yes, 50A rating handles heavy-duty commercial equipment. Double pole switching provides complete isolation for safety maintenance.
-
What does the neon indicator show?
Red neon indicator illuminates when switch is in 'ON' position, providing clear visual confirmation of circuit status.
-
Does this switch comply with current wiring regulations?
Fully compliant with BS EN 60669-1 standards, IP20 rated for indoor use, suitable for professional installations.
