Click CMA2503 50A 2-Gang Vertical DP Switch - White Rocker
50A double pole plate switch with 2-gang vertical configuration for high-load domestic appliances. Features screw terminals accepting 16mm² conductors, twin earth terminals, and BS EN 60669-1 compliance. Red LED indicator confirms switching status with antimicrobial certified white rocker finish. Requires 35mm minimum backbox depth for flush mounting. Terminal torque setting 2.5Nm with Ø6mm terminals for secure professional installation. 25-year warranty covers urea formaldehyde front plate with rounded profile styling.
Online:
Product Features
| Current Rating | 50A resistive load |
|---|---|
| Configuration | 2-gang vertical DP switching |
| Operating Voltage | 250V AC, 50Hz |
| Terminal Type | Screw terminals, Ø6mm |
| Terminal Capacity | 1 x 16mm² conductor |
| Terminal Torque | 2.5Nm maximum |
| Backbox Compatibility | 35mm minimum depth |
| Compliance | BS EN 60669-1, IP20 rated |
| LED Indicator | Red ON/OFF status indicator |
| Twin Earth | Pre-fitted earth terminals |
| Antimicrobial | 99.9% bacteria kill rate certified |
| Warranty | 25 years manufacturer warranty |
Installation Requirements
Terminal Specifications
Ø6mm screw terminals with 2.5Nm torque setting. Single 16mm² conductor capacity with twin earth terminals pre-fitted for faster installation.
Mounting Dimensions
86 x 146 x 9.5mm plate dimensions with 120.6mm vertical fixing centres. Requires 35mm minimum backbox depth for flush mounting.
Technical Compliance
Electrical Standards
BS EN 60669-1 compliant double pole switching with IP20 rating. Operating temperature range -5°C to +40°C with UKCA certification.
Material Specification
Urea formaldehyde front plate with brass terminals featuring silver overlay contacts. Antimicrobial certification provides 99.9% bacteria reduction.
Applications
Electric Cookers
50A rating suitable for dedicated cooker circuits up to 10kW. Double pole switching provides complete isolation for maintenance safety.
Immersion Heaters
Ideal for 3kW immersion heater switching with LED status indication. Vertical 2-gang configuration allows dual appliance control.
High-Load Appliances
Professional switching for electric ovens, commercial equipment, and other high-current domestic appliances requiring 50A capacity.
Frequently Asked Questions
-
What backbox depth is required for the CMA2503 switch?
Requires minimum 35mm backbox depth for flush mounting. Fixing centres are 120.6mm vertical spacing for standard 2-gang installation.
-
What cable size do the terminals accept?
Screw terminals accept single 16mm² conductor with Ø6mm terminal posts. Terminal torque setting is 2.5Nm maximum for secure connection.
-
Is this switch suitable for cooker circuits?
Yes, 50A rating handles resistive loads including electric cookers and immersion heaters on dedicated circuits up to 250V AC.
-
What does the LED indicator show?
Red LED indicates switching status with clear ON/OFF markings. Confirms load switching for high-current appliances without voltage testing.
